ViewEra V191 - Manual (Page 28)

27
8. Specifications
Specifications are subject to change without notice. The following specification sheet may not be
updated with specification or design changes. For the latest specification information, please refer to
ViewEra’ s product page on the website.
a. 15
”
security monitor
V151 BN Series
Panel Type:
Screen Size:
Pixel Pitch:
Brightness:
Contrast Ratio:
Response Time:
Viewing Angle(H / V)
Max. Resolution:
Display Color
Active TFT-LCD
15”
diagonal
0.297 (W) x 0.297 (H) mm
Typical: 250 cd/
Typical: 500:1
Typical: 12 ms
Typical: 130 / 120
1024 (W) x 768 (H)
16.2 M
Video Input
Video Output Analog: 15-pin, D-sub connector x 1, BNC IN x1,
BNC OUT x1
Power Supply
Input voltage:
Output rating:
100-240V /60-50Hz
12V DC,
3.0A
Power Consumption 25 watts (max.), 3 watts (standby)
Audio 2 watts x 2 built-in speakers
Frequency Horizontal:30-61 KHz; Vertical: 50-75 Hz
Dimensions (set size) 13.7 (W) x 13.3 (H) x 5.5 (D) inch
[346 (W) x 337 (H) x 140(D) mm]
Safety & EMI UL, CUL, FCC-B, CB, CE, TUV/GS
Weight N.W.: 6.0 lbs (2.7 Kg)
G.W.: 9.0 lbs (4.1 Kg)
Operating Conditions 5°C – 35°C; 20%-80% RH
Storage Conditions: -20°C – 60°C; 10%-90% RH
Wall mount VESA 75 bracket
