Viper SCRUBBER FANG 18C - Manual (Page 8)

USER MANUAL ENGLISH
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options,
according to the machine specific use:
1．Brush
2．Pad driver
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Model FANG 18C
Solution Tank Capacity 30 liter
Recovery Tank 41 liter
Cleaning Path 45 cm (18")
Pad Pressure 30 kg
Squeegee Width 75 cm (28")
Coverage Rate (max) 1100 m
2
/hr
Drive System Pad assist
Brush Motor 750 W
Vacuum Motor 2-stage
Waterlift 158.1 cm
Power Cable 25 m
Amp. 8.8 Amp
Max Gradient 2%
Weight (machine only) 65.5 kg
Dimensions
Length 110 cm
Width 54.5 cm
Height 97 cm
80188EU(1)2009-01 FANG 18C 7
