ENGLIS USER MANUAL ENGLISH
MACHINE DESCRIPTION
MACHINE STRUCTURE
1. Solution Tank
2. Recovery Tank
3. Clear Cover
4. Control Box
5. Switch lever
6. Drain Hose
7. Vacuum Hose
8. Water Hose
9. Squeegee Assembly
10. Transport Wheels
11. Bumper
12. Skirt
13. Brush Motor Switch
14. Vacuum Motor Switch
15. Knob
16. Plate
3
4
2
5
6
7 1
12
8
15
9
10
14 13
10 11
16
6 FANG 18C 80188EU(1)2009-01
