Connecting to a Sound System (Mixer, amplifier, recording device, etc.)
Connecting Audio
The
DA-1055 PRO has three audio output channels for connecting to mixers, amplifiers, recording devices, etc.
• MIX 1 and MIX 2 simultaneously output source player music and microphone vocals.
• LINE outputs the EQ channels with the source player music only for more convenient mixing of the EQ channels.
NOTE: Microphone vocals are not present in the LINE channel.
What you will need:
• Pair of
RCA audio cables. In most cases these are color coded red and white
• Mixer, amplifier, recording device, etc.
Connecting MIX 1 and MIX 2
Using the
MIX 1 and 2 AUDIO OUT channels you can connect music and vocals to two different audio devices.
1. Connect an end of each
RCA cable to the MIX 1 L/R RCA output jacks on the rear panel of the DA-1055 PRO.
2. Connect the other end of each
RCA cable to the L and R RCA input jacks on a mixer, amplifier, recording device, etc.
3. To connect to an additional device, follow steps
1 and 2 except now connect to the MIX 2 L/R RCA output jacks on the
rear panel of the
DA-1055 PRO.
Connecting Music-Only Using LINE OUT
1. Connect an end of each
RCA cable to the LINE L/R RCA output jacks on the rear panel of the DA-1055 PRO.
2. Connect the other end of each
RCA cable to the L and R RCA input jacks on a mixer, amplifier, recording device, etc.
