Vision Model 60™ Vision Model 80™
Projector Type: D-ILA, 3-Chip, 0.7 in. diagonal D-ILA, 3-chip, 0.82 in. diagonal
Native Resolution: 1400 x 788 (16:9) 1920 x 1080 (16:9)
Aspect Ratio: 4:3, Letterbox, 16:9 Anamorphic 4:3, Letterbox,16:9 Anamorphic
Video Standards: NTSC, PAL NTSC, PAL
DTV Compatibility: 480p, 720p, 1080i 480p, 720p, 1080i, 1080p
Picture Size
(16:9 Screen):
Recommended Width: 72 – 96 in.
Maximum Width: 240 in. Recommended Width: 72 – 96 in.
Maximum Width: 240 in.
Throw Distance
(Factor x Screen
Width):
2.00:1 to 2.50:1
1.60:1 to 2.00:1 with optional 0.8 short
throw external precision adapter lens
2.40:1 to 3.00:1 with optional 1.2 long
throw external precision adapter lens 1.81:1 to 2.33:1
1.44:1 to 1.86:1 with optional 0.8 short
throw external precision adapter lens
2.18:1 to 2.79:1 with optional 1.2 long
throw external precision adapter lens
Light Output: CSMS™* Specifications: Home Theater
Calibration: 487 ANSI Lumens;
17.9 Foot-Lamberts (fL);
1000 ANSI Lumens CSMS™* Specifications: Home Theater
Calibration: 491 ANSI Lumens;
18.1 Foot-Lamberts (fL);
1050 ANSI Lumens
Contrast Ratio: 1500:1 ANSI 2100:1 ANSI
Lamp: 250 W UHP 250 W UHP
Estimated Lamp Life: 2000 hours 2000 hours
Inputs: (1) Composite Video, (1) S-video,
(1) RGB/Component (via BNC),
(1) RGB (15-pin mini D-sub),
(1) DVI w/ HDCP, (1) RS-232,
(1) 1/8 in. mini stereo audio (1) DVI w/HDCP
(1) RS-232
12V Output Max 0.1 Amp, active when the projector is on
Power Requirements: 100 – 240V AC, 340W 100 – 240V AC, 350W
Operating Environ-
ment:
40° – 95° F, (5° – 35° C), 0% – 90% Humidity
(non-condensing) 40° – 95° F, (5° – 35° C), 0% – 90% Humidity
(non-condensing)
Dimensions (w/o
feet):
Width: 18 in. (457.2 mm)
Depth: 20 1/8 in. (511.18 mm)
Height: 6 in. (152.4 mm)
Weight: 40 lbs. (18.14 kg) Width: 18 in. (457.2 mm)
Depth: 20 1/8 in. (511.18 mm)
Height: 6 in. (152.40 mm)
Weight: 40 lbs. (18.14 kg)
Regulatory Approvals: Complies with FCC, CE, C-Tick Complies with FCC, CE, C-Tick
Limited Warranty: Projector: (2) Two years parts and labor
from the date of delivery to the end user
Lamp Warranty: 1000 hours or (6) six
months, which ever comes first. Projector: (2) Two years parts and labor
from the date of delivery to the end user
Lamp Warranty: 1000 hours or (6) six
months, which ever comes first.
Vidikron
2900 Faber Street
Union City, CA 94587
510-324-5900
Fax 510-324-5905
www.vidikron.com
*Cinema Standards Measurement System. See www.vidikron.com for more details.
Specifications are subject to change without notice. Optional ceiling mount available.
© 2005 Vidikron, a Runco International Company. All rights reserved.
Vision, Imagix, and CSMS are trademarks of Vidikron. ISF is a registered trademark of
Imaging Science Foundation. D-ILA is a trademark of Victor Company of Japan, Limited.
Theater installations by Homevision, North Miami, FL.
Theater interior design by First Impressions, North Miami, FL.
Going Beyond Home Theater ™
VDP-80™
Video Standards: NTSC, PAL
Output Resolution: 1080p
Outputs: (1) HD – R (Pr), G (Y), B (Pb), H, V
(1) DVI w/HDCP
Analog Inputs: Analog inputs can be configured in
memory for various combinations.
A typical example would be:
(1) Composite; (1) S-Video;
(2) Component; (2) RGB; (2) SDI
Digital Inputs: (2) DVI w/HDCP
Control Options: Discrete infrared remote; (1) RS-232
Power Requirements: 5V DC via supplied 100 – 240 V AC (auto
sensing) 50/60 Hz, 30 W AC/DC adapter
Operating Environment: 41 – 95 F, (5 – 35 C)
Dimensions: Width: 17 7/16 in. (442.92 mm)
Depth: 11 3/8 in. (288.92 mm)
Height: 3 1/2 in. (88.90 mm)
Weight: 15 lbs. (6.8 kg)
Regulatory Approvals: FCC, CE, C-Tick
Limited Warranty: (2) years parts and labor from the date of
delivery to the end user
Engineered for ISF ® calibration.
