www.VIZIOCE.com Version- 10/5/05
24
VIZIO L7 HDTV User Manual
2.3.2 - Using RGB Video
Connecting Set-Top Box (Better):
1. Turn off the power to your LCD TV and HDTV Set-Top box.
2. Connect a 15-pin D-Sub Rgb cable to the Rgb output of your HDTV Set-Top box and the other end to
the Rgb input (purple color area) in the rear of your LCD TV.
. Connect the Audio Out on your HDTV Set-Top box to the Audio within the Rgb group (purple color
area) on your LCD TV.
4. Turn on the power to your LCD TV and HDTV Set-Top box.
5. Select Rgb using the INPUT button on the front of your LCD TV or directly by pressing the Rgb button
on the Remote Control.
Note: Refer to your HDTV Set-Top box user manual for more information about the video output
requirements of the product or consult your satellite or cable operator.
