5

Installation

4. Installation :

Plug two SATA cables(Red) into the SATA
ports on the motherboard.

( Figure 5-D )

(5-4)

( Figure 5-A )

( Figure 5-B )

(5-1) Please remove the side panels of the case to
gain access to the chassis. Once inside,
remove the 5.25" front panel where you wish
to place the card reader.

( Figure 5-A )

(5-2) Insert the UGT-955-BK into the 5.25" bay as
shown in the figure.

( Figure 5-B )

(5-3) Tighten the screws of both sides.

( Figure 5-C )

( Figure 5-C )

( Figure 5-D )

(SATA Cable)

SAT

A

All in 1 Multifunction Internal Card Reader
