- 80 -
www.vivotek.com
T: 886-2-82455282
F: 886-2-82455532
blcarea(5)
(r/w) 0~255 Sixth row in BLC area.
Drive the Digital Output
Note: This request requires the privilege of I/O access control.
Method: GET/POST
Syntax:
http://<servername>/cgi-bin/setdo.cgi?do1=[&do2=]
[&do3=][&do4=][&return=]
Where state is H, L. H means NC (normal close) connected with COMMON and L means
NO (normal open) connected with COMMON. The number of DO dependents on the
server type.
parameter Value
description
H – NC connected with COMMON
do
L – NO connected with COMMON
return
Redirect to the page after the
parameter is assigned. The can be
a full URL path or relative path according the the
current path. If you omit this parameter, it will
redirect to an empty page.
Example: Drive the digital output 1 to high and redirect to an empty page
http://myserver/cgi-bin/setdo.cgi?do1=H
Query Status of the Digital Input
Note: This request requires the privilege of I/O access control.
