- 4 -
• See the voltage, frequency and current from the label on the back or
side of the cooling unit.
The dimension and capacity are specified as follows:
MODEL
COOLING
CAPACITY,
CFM
55
°
F/75
°
F
BOTTLE
CAPACITY
55
°
F/75
°
F
DIMENSIONS IN.
WXHXD
ELECTRICAL
WEIGHT
(lb)
VINO-
1500HZD
1500 Btu/h,
120 CFM
150
cu ft
800
bottles
14.25X13.25X 16 115V/60HZ/4A 50
VINO-
2500HZD
2500 Btu/h,
180 CFM
250
cu ft
1200
bottles
14.25X13.25X 16 115V/60HZ/5A 55
VINO-
3500HZD
3500 Btu/h,
250 CFM
650
cu ft
3000
bottles
14.25x19.75x21.25 115V/60Hz/6A 75
VINO-
4500HZD
4500 Btu/h,
250 CFM
1000
cu ft
4500
bottles
14.25x19.75x21.25 115V/60Hz/9A 75
VINO-
6500HZD
6500 Btu/h,
500 CFM
1500
cu ft
6500
bottles
17x22x28 115V/60Hz/14A 110
VINO-
8500HZD
8500 Btu/h,
500 CFM
2000
cu ft
8500
bottles
17x22x28 115V/60Hz/16A 110
Fig. 1.2 DIMENSIONS
