TOA VS-900 Programmer’s Guide
11
Station Call Reception
Field Name Length
(Bytes) Value Description Direction
DLE 1 10H Delimiter
ENQ 1 05H Enquiry
VS-900 to PC
DLE 1 10H Delimiter
ACK 1 06H Acknowledge
PC to VS-900
DLE 1 10H Delimiter
STX 1 02H Start Of Text
Log Data 1 6FH Log Data
Exchange # 2 30H 31H Exchange # “01”
Time (HH:MM:SS) 6 31H 36H 33H 37H 32H 33H Time: “16:37:23"
Line #1 6 32H 30H 30H 20H 20H 20H Master Station # “200”
Line #2 6 20H 20H 20H 20H 20H 20H First Waiting station #
(Blank)
Line #3 6 20H 20H 20H 20H 20H 20H Not Used (Blank)
Line #4 6 20H 20H 20H 20H 20H 20H Not Used (Blank)
Status # 2 30H 35H “05” (Station call
reception)
DLE 1 10H Delimiter
ETX 1 03H End Of Text
BCC 1 68H Block Check Character
VS-900MF to PC
DLE 1 10H Delimiter
ACK 1 06H Acknowledge
PC to VS-900
DLE 1 10H Delimiter
EOT 1 04H End of Transmission
VS-900MF to PC
Call Operation Completion
Field Name Length
(Bytes) Value Description Direction
DLE 1 10H Delimiter
ENQ 1 05H Enquiry
VS-900 to PC
DLE 1 10H Delimiter
ACK 1 06H Acknowledge
PC to VS-900
DLE 1 10H Delimiter
STX 1 02H Start Of Text
Log Data 1 6FH Log Data
Exchange # 2 30H 31H Exchange # “01”
Time (HH:MM:SS) 6 31H 36H 33H 37H 32H 37H Time: “16:37:27"
Line #1 6 32H 30H 30H 20H 20H 20H Master Station # “200”
Line #2 6 31H 30H 35H 20H 20H 20H Called Station # “105”
Line #3 6 20H 20H 20H 20H 20H 20H Not Used (Blank)
Line #4 6 20H 20H 20H 20H 20H 20H Not Used (Blank)
Status # 2 30H 39H “09” (Call operation
completion)
DLE 1 10H Delimiter
ETX 1 03H End Of Text
BCC 1 74H Block Check Character
VS-900MF to PC
DLE 1 10H Delimiter
ACK 1 06H Acknowledge
PC to VS-900
DLE 1 10H Delimiter
EOT 1 04H End of Transmission
VS-900MF to PC
