CUSTOM PANEL–REFRIGERATION
Built-In 42”W. Side-By-Side Refrigerator/Freezer &
Refrigerator/Freezer with Dispenser—DFSB423/423D
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 8 / 1 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Dimensions & Specifications
DFSB423 DFSB423D
CUSTOM SIDE PANEL DIMENSIONS
Note: Adding a 3/4” (1.9 cm) side panel adds an additional 3/4” (1.9 cm) to the overall width of the product for each side panel.
Requires side panel hardware kit (Kit model number – SPHKDS)
DFSB423/DFSB423D
Overall panel width 3/4” (1.9 cm)
Overall panel height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.*
Overall panel depth 24” (61.0 cm)
*Depending on how high leveling feet are raised and cabinet enclosure height.
3/4”
(1.9 cm)
End panel
1”
(2.5 cm)
1/4”
(0.6 cm)
Z-Bracket
21-
3/4
”
(55
.2 c
m)
21-
3/4
”
(55
.2 c
m)
24”
(61
.0 c
m)
Optional kickplate notch
Dimensions determined by cabinets
24”
(61
.0 c
m)
82-7
/8”
(210
.5 cm
) min
.
to 84-1
/16”
(213
.5 cm
) ma
x.*
82-7
/8”
(210
.5 cm
) min
.
to 84-1
/16”
(213
.5 cm
) ma
x.*
