Installation – Vantec NST-D100FBSU User Manual

Page 6

  • Text mode
  • Original mode
background image

5

4.Installation

1. Connect the power adapter to the NexStar Hard Drive Dock.
2. Connect either the USB, eSATA or FireWire Cable to the NexStar Hard Drive Dock and

attach the other end to your computer.

Power

Cable

USB 2.0

Cable

OR

OR

Firewire

Cable

SATA

IEE

E

1394B

IEE

E

1394B

eSATA

Cable
