51
ENGLISH
Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775
ViewSonic VTMS2431
Other Information
If the Command is Not valid, Command Type= “-”, Only for HDTV power status on
standby.
Name Length Command
Type
CR
Byte Count 1 Byte 1 Byte 1 Byte
Bytes order 1 2 3
Example1: Get power status on standby and this command is valid.
Send (Hex Format)
Name Length Command
Type
Command Value1 Value2 Value3 CR
Hex 0x36 0x67 0x6C 0x30 0x30 0x30 0x0D
Reply (Hex Format)
Name Length Command
Type
Command Value1 Value2 Value3 CR
Hex 0x36 0x72 0x6C 0x30 0x30 0x30 0x0D
Example2: Get Brightness from TV-05 and this command is valid.
The Brightness value is 67.
Send (Hex Format)
Name Length ID Command
Type
Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x35
0x67 0x62 0x30 0x30 0x30 0x0D
Reply (Hex Format)
Name Length ID Command
Type
Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x35
0x72 0x62 0x30 0x36 0x37 0x0D
Example3: Get Brightness from TV-05 , but the Brightness command ID is error
and it is NOT in the command table.
Send (Hex Format)
Name Length ID Command
Type
Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x35
0x67 0xD3 0x30 0x30 0x30 0x0D
Reply (Hex Format)
Name Length ID Command
Type
CR
Hex 0x34 0x30
0x35
0x2D 0x0D
