47
ENGLISH
Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775
ViewSonic VTMS2431
Other Information
Reply (Command Type= “+” or “-”)
Name Length ID Command
Type
CR
Byte Count 1 Byte 2 Byte 1 Byte 1 Byte
Bytes order 1 2~3 4 5
(Command Type= “+” or “-”, Only for HDTV power on)
Name Length Command
Type
CR
Byte Count 1 Byte 1 Byte 1 Byte
Bytes order 1 2 3
Example1: Set HDTV power on and this command is valid.
Send (Hex Format)
Name Length Command
Type
Command Value1 Value2 Value3 CR
Hex 0x36 0x73 0x21 0x30 0x30 0x31 0x0D
Reply (Hex Format)
Name Length Command
Type
CR
Hex 0x32 0x2B 0x0D
Example2: Set Brightness as 76 for TV-02 and this command is valid.
Send (Hex Format)
Name Length ID Command
Type
Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x32
0x73 0x24 0x30 0x37 0x36 0x0D
Reply (Hex Format)
Name Length ID Command
Type
CR
Hex 0x34 0x30
0x32
0x2B 0x0D
