FIGURE 3

SPINDLES

(Serial # AA1007-AA1275)

REF.

PART NO.

DESCRIPTION

QTY.

1 . . . . . . 99.A12NF . . . . . . . . 3/4-16 Lock Nut . . . . . . . . . . . . . . . . . . 3
2*. . . . . . 95.12 . . . . . . . . . . . 3/4 SAE Washer . . . . . . . . . . . . . . . . . . 3

. . . . . . . 99.B0057-2 . . . . . . . . 3/4 x 1-1/4 10GA Machine Washer . . . . . . . . 3

3*. . . . . . 83.0036. . . . . . . . . . D-Hex Top Mount Pulley . . . . . . . . . . . . . . 2

. . . . . . . 83.0048. . . . . . . . . . D-Hex Pulley . . . . . . . . . . . . . . . . . . . . 3

4 . . . . . . 90.0610. . . . . . . . . . 3/8-16 x 1-1/4 Bolt . . . . . . . . . . . . . . . . . 24
5 . . . . . . 95.06 . . . . . . . . . . . 3/8 SAE Washer. . . . . . . . . . . . . . . . . . 24
6 . . . . . . 55.0035. . . . . . . . . . Spindle Bearing . . . . . . . . . . . . . . . . . . 6

7 . . . . . . 87.0178. . . . . . . . . . Spindle Housing . . . . . . . . . . . . . . . . . . 3
8 . . . . . . 87.0179. . . . . . . . . . Bearing Spacer. . . . . . . . . . . . . . . . . . . 3
9 . . . . . . 29.GF0001 . . . . . . . . 1/4-28 Grease Fitting . . . . . . . . . . . . . . . 3
10 . . . . . 99.SF06 . . . . . . . . . 3/8-16 Flange Nut . . . . . . . . . . . . . . . . . 24
11* . . . . . 87.0181. . . . . . . . . . Spindle Shaft - Right Hand Thread . . . . . . . . 2

. . . . . . . 87.0206-1 . . . . . . . . Spindle Shaft - Right Hand Thread . . . . . . . . 2

12* . . . . . 87.0184-1 . . . . . . . . Spindle Shaft - Left Hand Thread . . . . . . . . . 1

. . . . . . . 87.0205-1 . . . . . . . . Spindle Shaft - Left Hand Thread . . . . . . . . . 1

13* . . . . . 87.0184. . . . . . . . . . Spindle Assembly - 1/2-20 LH Thread . . . . . . . 1

. . . . . . . 87.0205. . . . . . . . . . Spindle Assembly - 1/2-20 LH Thread . . . . . . . 1

14* . . . . . 87.0176. . . . . . . . . . Spindle Assembly - 1/2-20 RH Thread. . . . . . . 2

. . . . . . . 87.0206. . . . . . . . . . Spindle Assembly - 1/2-20 RH Thread. . . . . . . 1

15 . . . . . 79.0048. . . . . . . . . . Bi-directional Blade . . . . . . . . . . . . . . . . 3
16 . . . . . 64.0688. . . . . . . . . . Spindle Guard . . . . . . . . . . . . . . . . . . . 3
17 . . . . . 91.0810. . . . . . . . . . 1/2-20 x 1-1/4 Bolt . . . . . . . . . . . . . . . . . 2
18 . . . . . 91.0810L . . . . . . . . . 1/2-20 x 1-1/4 LH Bolt . . . . . . . . . . . . . . . 1

19* . . . . . 83.0043. . . . . . . . . . D-Hex Bottom Mount Pulley (same as item 3 now) 0
20 . . . . . 81.AA060 . . . . . . . . . AA60 Belt . . . . . . . . . . . . . . . . . . . . . 1
21 . . . . . 81.B158 . . . . . . . . . B158 Belt (Dayco/Carlisle - No longer available) . 1

. . . . . . . 81.B162 . . . . . . . . . B162 Belt (Goodyear - Current replacement) . . . 1

E-6

PARTS & DRAWINGS

* Note: Beginning with serial number AA1150, item 2, 3, 11, 12, 13, 14, & 19 were replaced as follows:

95.12 replaced by 99.B0057-2. 83.0036 replaced by 83.0048. 87.0181 replaced by 87.0206-1.

87.0184-1 replaced by 87.0205-1. 87.0184 replaced by 87.0205. 87.0176 replaced by 87.0206.
83.0043 replaced by 83.0048(same as item 3) .
