OWNER’S MANUAL
PARTS LIST
VMH26NR
This list contains replaceable parts used in
your fireplace. When ordering parts, follow
the instructions listed under Replacement
Parts on page 27 of this manual.
KEY NO. PART NO. DESCRIPTION QTY.
1 102633-02CK Outer Casing Top 1
2 102624-02 Outer Casing 1
3 099230-02 Shoulder Screw 16
4 098304-01 Screw, #10 x 3/8" 17
5 103447-02 Burner 1
6 103209-03 Louvered Door 1
7 102635-02CK Left and Right Side Front 2
8 103209-01 Brass Top Louver 1
9 101712-04 Firebox Hood 1
10 102638-01 Firebox Top 1
11 103779-01 ODS/Pilot Assembly 1
12 102460-01CJ Firebox Wrapper 1
13 104322-01 Burner Tube 1
14 104335-01CK Outer Shell Base 1
15 102649-02CJ Branch Support 1
16 097159-04 Piezo 1
17 099918-02 Regulator, Pilot 1
18 098271-07 Ignitor Cable 1
19 103845-11 Injector 1
20 102458-01CK Middle Rail 1
21 098249-01 Nut, M5 6
22 103781-01 Gas Valve 1
23 102639-01 Baffle 1
24 101628-01 Flexible Connector 1
25 104305-01 Control Shield 1
26 103295-01CJ Screen Assembly 1
27 103058-01 Log Set Assembly 1
27-1 104058-01 Branch Service Kit 1
27-2 104058-02 Back Log Service Kit 1
28 104313-01 Right Hinge 1
29 104313-02 Left Hinge 1
30 M10908-2 Hinge Screws 4
31 102645-02 Burner Support, Right 1
32 102645-03 Burner Support, Left 1
33 097809-02 Connector, Male 1
34 101629-01 Bushing 1
35 101629-02 Bushing 1
36 M12461-26 Gas Valve Screws 4
37 103587-02 Plate, Switch 1
38 099998-01 Switch, Fan 1
39 098264-02 Connector, Male 1
40 103284-03 Wire Harness 1
41 099387-14 Pilot Tube to Regulator 1
42 099387-15 Pilot Tube, Reg. to Control Valve 1
43 M11084-26 Screw, Hex Head, #10 x 3/8" 25
PARTS AVAILABLE — NOT SHOWN
104319-02 Information Video 1
103877-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
103470-02 Hardware Package 1
