V Shift Setting

Project image onto the screen

2.35:1 Cinemascope image

Press the [MENU] button

• The main menu is displayed on the screen.

��

ENTER

��

�

��

��
��

��

Press [5/6

// ] to select “Options”, followed by pressing [ENTER]

• The “Options” menu appears on the right side of the screen.

��

TEST

PRESET

ENT

MUTE

LIGHT

2, 5

3, 4

2, 5

3, 4

Press [5/6

// ] to select “V Shift”, followed by pressing [3/4] to

select the setting value

• Set value in the positive (+) direction to move the image upwards and

negative (-) direction to move downwards.

��

➭

Press the [MENU] button to end

• The menu will disappear from the screen.

When projecting images with black bands at the top and bottom such as a 2:35 Cinemascope image, use this to move the image up or
down while retaining one of the black bands at the upper or lower end.

E.g.: When “Picture Shift” value is changed
from “0” to “30”
