UGT‐PC2S1P Page 5
Hardware Installation
1.
Turn off the power to your computer.
2.
Unplug the power cord and remove your computer’s cover.
3.
Remove the slot bracket from an available PCI slot.
4.
To install the 2+1 SERIAL & PARALLEL PCI HOST CARD,
carefully align the card’s bus connector with the selected PCI slot
on the motherboard. Push the board down firmly.
5.
Replace the slot bracket’s holding screw to secure the card.
6.
Replace the computer cover and reconnect the power cord.
Driver Installation
Note: Driver can also be found and downloaded from our website at
For Windows® 2000
1.
At the Windows desktop click Start, then Run.
2.
Type D:\UGT-PC2S1P \2000\PciSetup.exe, then click OK.
3.
Press “Install” button to install the drivers.
4.
Click “Exit” button.
5.
Restart Windows to complete the installation.
