OWNER’S MANUAL
PARTS LIST
VN2550ITB
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 22 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 098742-14 Front Panel 1
3 098238-07 Grill Guard 1
4 101108-01 Clip-Grill Guard 2
5 098198-04 Apron 1
6 M11084-26 Screw, #10 x 3/8" 9
7 098462-01 Control Rod Assembly 1
8 098457-05 Reflector Assembly 1
9 099415-08 Regulator 1
10 M11084-38 Screw, #8 x 3/8" 2
11 104617-02 Cabinet Assembly 1
12 098324-01 Control Knob 1
13 098325-01 Roll Pin 1
14 097159-04 Piezo Ignitor 1
15 100537-02 Regulator Bracket 1
16 098522-16 Thermostat Gas Valve 1
17 098271-03 Cable Ignitor 1
18 104224-01 SIT Tubing 1
19 104197-01 Inlet Tubing 1
20 099211-01 Hex-Head Screw 2
21 See Detail Burner Assembly 1
21-1 099218-03 Burner 1
21-2 098508-01 Valve Retainer Nut 1
21-3 099056-06 Injector 4
21-4 100620-01 Tubing-Valve to Plaque A 1
21-5 100607-02 Tubing-Valve to Plaque B 1
21-6 100608-01 Tubing-Valve to Plaque C 1
21-7 100605-02 Control Valve 1
21-8 100616-02 Control Valve Tube 1
21-9 099387-06 Pilot Tubing 1
21-10 103594-07 ODS/Pilot 1
21-11 100606-01 Tubing - Valve to Plaque D 1
21-12 100615-01 Male Connector 2
21-13 M11084-37 Screw, #8 x 1/4" 4
21-14 M11084-26 Screw, #10 x 3/8" 2
21-15 098514-01 Thermocouple 1
21-16 106842-01 Ignitor Electrode 1
22 099066-01 Mounting Bracket 1
PARTS AVAILABLE - NOT SHOWN
100619-01 Thermostat Control Position Label 1
100619-02 Control Position Label 1
100642-01 Hardware Assembly 1
