2
Getting started
Telephone base and charger installation
Install the telephone base and charger as shown below.
Make sure that the electrical outlet is not controlled by a wall switch.
If you subscribe to digital subscriber line (DSL) high-speed Internet service
through your telephone line, you must install a DSL filter between the
telephone line cord and telephone wall jack. The filter prevents noise and
caller ID problems caused by DSL interference. Contact your DSL service
provider for more information about DSL filters.
Use only the power adapters and batteries supplied with this product.
To order a replacement, visit our website at www.vtechphones.com or
call 1 (800) 595-9511. In Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
The power adapters are intended to be correctly oriented in a vertical
or floor mount position. The prongs are not designed to hold the plug in
place if it is plugged into a ceiling, under-the-table or cabinet outlet.
•
•
Wall mounting
Your telephone comes ready for tabletop use. If you prefer to mount your
telephone on the wall (optional), it is designed to mount on a standard
telephone wall plate.
You can mount the telephone base on the wall by positioning the
top hole at the back of the telephone
base against the top mounting
stud [A]. Then slide the telephone
base down on the mounting
studs [A] and [B] until it locks
into place.
Mounting
studs
Telephone base
[A]
[B]
Telephone base
Telephone
line cord
Electrical outlet
(not controlled
by a wall switch)
Telephone
wall jack
A DSL filter (not
included) is
required if you have
DSL high-speed
Internet service
Telephone base
power adapter
Charger
Charger
adapter
