VIZIO GV47L FHD TV User Manual
Version 5/18/2007 11
www.VIZIOCE.com
1.3 Rear Panel Connections
Left Portion
1. SPEAKER – Connection for right speaker.
2. AC IN – Plug-in the supplied AC Power Cord here.
3. DTV – Connect to an antenna or cable/digital cable for TV and Digital TV.*
4. OPTICAL DIGITAL AUDIO OUT – When the DTV input is selected for viewing, the digital
audio associated with digital programming will be available on this SPDIF Optical connector
for connection to your home theatre system. The gray color band on the rear of the TV
indicates this connection.
* For digital TV stations in your area visit www.antennaweb.org .
1 2 3 4
