Orange bag – Vision Fitness R2200 User Manual
Page 5
5
1
STEP
1
STEP
• Slide the rear foot into place on the
frame. Secure the foot in place with
two screws (M8x20) and two lock
washers (M8) to the outside holes and
with two screws (M8x65) and two
lock washers (M8) to the inside holes.
Tighten with the blue-handled 5mm
allen wrench.
• Slide the rubber sleeve, located on
the rear support tube, into place over
the rear foot.
ORANGE BAG
Rear Foot
