Vivotek IP2112 User Manual
Page 39
38
“Digital input state”:
H (high), L (low), / (low to high), \ (high to low)
“M”:
motion
detection
event.
“Channel Number”:
always A
“Video input state”:
/ (signal from loss to presence), \ (signal from presence to
loss), X (as long as signal loss)
“Delay time”:
seconds of delay for the following actions after events happen
“Digital output number”: always 1
“Digital output state”: C (NC), O (NO)
“V”:
set
video
channel
to
go
to
preset
location
“P”:
set preset location number to go to preset location
“W”:
send
warning
to
server
“IP”:
server IP
“Port”:
server port
“Message”:
texts to be sent to the server
“U”:
upload
snapshots
“Method”:
‘F’ is by FTP, ‘M’ is by e-mail
“S”:
take
snapshot
“N”:
define
the
format
of
the
filename
“;”:
end
of
line
The filename format is,
%a
image characterization (pre, trg, pos)
%y
year
%M
month
%d
day
%h
hour
%m
minute
%s
second
%t
tenth second
