3 6 " , 4 8 " , A N D 6 0 " W I D E W A L L H O O D S
18" HIGH WALL HOOD CANOPY – 27" DEEP
Models
Number
of Lights
Number
of Filters Interior-Power Exterior-Power
Recommended Ventilator Kits
Interior Exterior
Recommended Duct Size
Interior Exterior
Maximum Amps
An interior- or exterior-power ventilator kit must be purchased for installation with all hoods.
Outdoor hoods
VWH3678T-36"W VIV1200 VEV1200/VEV1500 2 2 10" 8.7 6.1/6.8 10"/10"
VWH4878T-48"W VIV1200 VEV1200/VEV1500 3 3 10" 11.5 8.8/9.5 10"
VWH6078T-60"W VIV1200 VEV1200/VEV1500 4 4 10" 11.5 8.8/9.5 10"
Ventilator kits
VEV1200
Approximate CFM 1
Recommended Duct Size
Maximum Duct Run 2
Maximum Amps
Description
V E N T I L A T O R K I T S
Interior Ventilators Exterior Ventilators
VIL1200 VIV1200
1,200 1,200
50 ft. (15.2 m) 50 ft. (15.2 m) 50 ft. (15.2 m)
1,200
S E E H O O D S P E C I F I C A T I O N S
S E E H O O D S P E C I F I C A T I O N S
Please note: Maximum amp rating for hoods includes recommended ventilator kit rating; all products must be hard wired with 2-wire ground. All ventilator kits use 120VAC/60Hz
Proper installation is extremely important to ensure maximum performance from any ventilation product.
1. All CFMs stated based on tests with .1 static pressure; without applying static pressure (some brands consciously do not), CFM could be greatly overstated.
2. Duct run length is for general reference only; for longer duct runs, increase duct size and contact a qualified and trained installer.
• Straight runs and gradual turns are best; for example, each 90-degree elbow is equal to 5-10 feet (1.52-3.05 m) of straight run.
• Never use flexible duct; it creates back pressure/air turbulence and greatly reduces performance.
• Proper performance is dependent upon proper ducting; make sure that a qualified and trained installer is used.
• Check with a qualified and trained installer or local codes for makeup air requirements, if any.
45
Access doors
Description
Overall Width
(including notches)
AD2820T AD1620T
28 1/4" (71.8 cm) minimum
30 1/4" (76.8 cm) maximum
D O U B L E A N D S I N G L E A C C E S S D O O R S
16 1/4" (41.3 cm) minimum
18 1/4" (46.4 cm) maximum
Overall Height
(opening only) 20 1/4" (51.4 cm) minimum
20 1/2" (52.1 cm) maximum
In-line ventilation kits
VEV1500
1,500
75 ft. (22.8 m)
