24
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
RF Unit
Parts List
C 1241 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- A C6
C 1242 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A C2
C 1243 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A C2
C 1244 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A C2
C 1245 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- B g6
C 1247 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B e3
C 1249 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1 B e2
C 1249 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 2- B e2
C 1251 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C3
C 1252 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A E5
C 1253 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B c4
C 1254 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A F5
C 1255 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B d3
C 1256 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A G4
C 1257 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A F4
C 1258 CHIP TA.CAP. 68uF 16V TEMSVD1C686M12R K78120034 1- B f2
C 1259 CHIP CAP. 22pF 50V CH GRM39CH220J50PT K22174219 1- B a5
C 1260 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B b2
C 1261 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B b4
C 1262 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A B3
C 1263 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B d4
C 1264 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A C3
C 1265 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B f6
C 1266 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B c3
C 1267 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A H4
C 1270 CHIP CAP. 1pF 50V CK GRM39CK010C50PT K22174202 1- A D5
C 1271 CHIP CAP. 220pF 50V CH GRM39CH221J50PT K22174243 1- A G3
C 1272 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B g3
C 1273 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A F3
C 1276 CHIP CAP. 15pF 50V CH GRM39CH150J50PT K22174215 1- A H3
C 1278 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1 B e3
C 1278 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 2- B e3
C 1279 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D2
C 1281 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A E2
C 1282 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B b4
C 1284 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- B a4
C 1286 CHIP CAP. 1pF 50V CK GRM39CK010C50PT K22174202 1- A G4
C 1291 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A E3
C 1292 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A D3
C 1293 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B e5
C 1294 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E3
C 1295 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B e3
C 1296 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A E3
C 1297 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B a6
C 1299 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D2
C 1301 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A E3
C 1303 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1-2 A E2
C 1304 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A D5
C 1305 CHIP CAP. 33pF 50V CH GRM39CH330J50PT K22174223 1- A E4
C 1306 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- A E5
C 1501 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B1
C 1502 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B1
C 1503 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1504 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B1
C 1505 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A A1
C 1506 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- B g1
C 1507 AL.ELECTRO.CAP. 100uF 16V ECEV1CA101WP K48120012 1- A C3
C 1508 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A C4
C 1509 AL.ELECTRO.CAP. 10uF 16V RV2-16V100MB55-R K48120014 1- A C4
C 1510 CHIP CAP. 1uF 10V F GRM39F105Z10PT K22105001 1- A B5
C 1511 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C4
C 1512 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A B5
C 1513 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C5
C 1515 AL.ELECTRO.CAP. 10uF 16V RV2-16V100MB55-R K48120014 1- A A5
C 1516 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B4
C 1517 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A B4
C 1518 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- B g4
C 1519 CHIP TA.CAP. 4.7uF 10V TEMSVA1A475M-8R K78100022 1- B e4
C 1520 AL.ELECTRO.CAP. 100uF 16V ECEV1CA101WP K48120012 1- A B4
C 1521 AL.ELECTRO.CAP. 470uF 16V RE3-16V471M 470UF K40129066 1- A A4
C 1522 CHIP CAP. 100pF 50V CH GRM39CH101J50PT K22174235 1- A B1
C 1523 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1 B f4
C 1523 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 2- B f4
C 1524 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- B g4
C 1525 CHIP CAP. 120pF 50V CH GRM39CH121J50PT K22174237 1- A C4
C 1526 CHIP CAP. 470pF 50V CH GRM39CH471J50PT K22174249 1- A C4
