Installation
In this manual, "User" refers to whoever has access to the Network Camera, and
"Administrator" refers to the person who can configure the Network Camera and grant
user access to the camera.
Hardware installation
Please verify that
your product package
contains all the
accessories listed in
the foregoing Package Contents. Depending on the
user’s application, an Ethernet cable may be needed.
The Ethernet cable should meet the specs of UTP
Category 5 and not exceed 100 meters in length.
Upon powering up, the LED will become lighted first and then the device will go through
booting process. The LED will be steady orange for getting IP address. After getting IP
Address, the LED will blink green every second and the red-color is always on.
The Network Camera will first detect Ethernet. Operating in either network mode, the
LED will blink green-color as heartbeat to indicate alive.
Connect the power adapter jack to the Network
Camera before plugging in to the power socket. This will
reduce the risk of accidental electric shock.
7 - User's Manual
VIVOTEK - A Leading Provider of Multimedia Communication Solutions
To install in Ethernet
Make sure the Ethernet is firmly connected to a switch hub. After attaching the Ethernet
cable plug in the power adapter. If the LED turns out to blink green-color, go to next
paragraph “Software installation”. If the Ethernet is not available, Network Camera will
switch to wireless LAN mode.
