Handset layout, Installation – VTech DS3111-3 User Manual
Page 13
www.vtechphones.com
10
Installation
Handset layout
1. Earpiece
2.
MENU/SELECT
SKIP (page 15)
3. Headset jack (2.5mm) (page 9)
4.
CID (caller ID) (page 28)
PLAY (page 15)
5.
/FLASH
6. Dialing keys (
0-9, *, #)
7.
VOICEMAIL (page 19)
8.
REDIAL/PAUSE (page 32)
9. Microphone
10. Handset display
11.
VOL / (volume) (page 18)
12. (directory) (page 23)
ERASE (page 15)
13. (speakerphone) (page 17)
14.
OFF/CLEAR
15.
#(page 29)
16.
INT (intercom) (page 20)
17.
MUTE/REMOVE (page 17)
