8 SCRUBBERS FANG20-EU / FANG20T-EU 82089E(1)2009-04A
ENGLISH USER MANUAL
ENGLISH
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specifi c use:
Neoprene squeegee blades
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Model
FANG20 - EU FANG20T - EU
(1 brush/pad-holder, without drive system) (1 brush/pad-holder, with drive system)
Machine height 990mm
Solution/clean water tank capacity 50 litres
Recovery water tank capacity 57 litres
Front wheel diameter 76 mm
Front and rear wheel specific pressure on the floor 0.9 N/mm 2 - 3 N/mm 2
Rear wheel diameter 200 mm
Vacuum system motor power 353 W
Drive system motor power — 250 W
Drive speed (variable) — 0 to 4.5 km/h
Gradeability 2 %
Sound pressure level at workstation 68 dB(A)
Standard batteries (2 x 12 V) 95 - 125 Ah @ 20 h
Battery compartment size (length x width x height) 340 x 345 x 300 mm
Vacuum system circuit capacity 1,200 mm H
2
O
Cleaning width 508 mm
Squeegee width 712 mm
Machine maximum length 1,300 mm
Machine width without squeegee 560 mm
Brush diameter 508 mm
Weight without batteries and with empty tanks 86 kg 92kg
Maximum weight with batteries and full tanks 200 kg 206 kg
Brush motor power 560 W
Brush speed 200 rpm
30 kg
19.0 kg 20.5 kg
Brush/pad-holder pressure with extra-pressure
30 kg
Brush/pad-holder pressure with extra-pressure
function turned off
function turned on
