ASSEMBLY
Assembly
1. Unpack unit and make sure all components are included; (4) Legs,
and all hardware for installation.
2. Fold the corner padding from the carton and lay it on the floor behind
the unit. This is used to hold the heater up off the floor to install the legs.
Gently tilt the heater on its back, door opening up.
3. Assemble the legs as shown using the eight(8) bolts supplied.
4. After all bolts and screws have been tightened properly, carefully set
the heater back up on the legs.
1. The Auger is packed in the hopper or ash
pan and must be installed properly as illustrated
below.
2. Insert the Auger into the auger tube. Rotate
the auger until it fits into the coupling that is
already installed on the auger motor drive. Seat
the auger firmly. The Auger cannot be turned
by hand once installed properly.
6039T ASSEMBLY
6039 PEDESTAL TRIM ASSEMBLY
Assemble trim pieces as shown with the screws
provided in the parts bag.
After trim assembly, attach to the pedestal base at the
location shown using the screws provided.
