BC-RH96 Connections
DC Power Input Jack
To Remote Cable
Mini-Plug
Cable Routing Guides
Data Port (for firm-
ware updates)
1
2
3
4
1
2
3
4
Always route both cables
through the channel.
Note: Connect the Remote Cable and route it through the cable channel as
shown. Then connect the DC Power Cable and route it through the channel.
