14 CO2175DWR
Leveling
NOTE: It is important that the unit is level. If unit is not
level, the ice mold may not fill evenly.
Figure 15
1. Use a level to check the levelness of the unit from
front to back and from side to side. Place the level
along top edge and side edge as shown (Figure 15).
Figure 16
2. If the unit is not level, adjust the feet on the corners of
the unit as necessary (Figure 16).
3. Check the levelness after each adjustment and repeat
the previous steps until the unit is level.
Light Bulb Replacement
To replace the light bulb in your U-Line unit:
Figure 17
1. Grasp the edges of the light housing lens
(Figure 17, 1) opposite the exposed tab and gently
push the lens toward the tab (Figure 17, 2).
2. Pull the edge of the lens down (Figure 17, 1) and
swing it out of the light housing.
IMPORTANT IMPORTANT
ALWAYS use a genuine U-Line replacement bulb (P/N
31317) in the light housing. Use of any other bulb
within the housing will generate excessive heat,
causing damage to the light housing and cabinet
interior, and will compromise the precise
temperature control of your unit.
3. Replace the bulb only with a genuine U-Line P/N 31317
replacement.
4. Replace the lens by first inserting the tab side back into
the housing at a slight angle. While gently pushing the
lens towards the tab end, push the free end up into the
housing, and release when you will hear a snap/click.
ULIN_0045_A
ULIN_0046_A
1
2
ULIN_0001_A
