UNICOM Electric 802.11b+g - Manual (Page 21)

Tx Frame
The quantities for the wireless network card transmit.
(Frame: The unit of packet)
Rx Frame
The quantities for the wireless network card receive.
(Frame: The unit of packet)
More Setting…
Channel The Channel will change automatically according to AP’s setting.
Tx Rate
Click the down arrow ▼ to select the Tx Rate from Auto, 1, 2,
5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54 Mbps, you can select up to 54
Mbps.
SSID
The SSID is the unique name shared among all points in your
wireless network. The name must be identical for all devices and
points attempting to connect to the same network.
Any
You may select to have SSID by choosing any, the SSID will be
obtained automatically from whichever Access Point with the
optimal signal for this device. If any is left unchecked, it means
you will have to enter the SSID manually.
- 18 -
