Figure 4.4 - Mode IV: Power Stereo
• Same as Mode I, except the Pre-Amplifier
sec tion has been bypassed.
• A separate pre-amplifier is needed to control
the volume.
L
1st AM -77
Power
Amp
(R)
Power
Amp
(L)
Left
Speaker
Right
Speaker
R
(L)
(R)
