Figure 2.1 - AM-77 Front Fascia
F5 F4 F3 F2 F1
DUAL MONO AMPLIFIER AM 77 - -
Section 2 - Component Overview
F1. STANDBY switch: to place the AM-77 in active or standby mode.
F2. SOURCE selection buttons: to select between the 5 different inputs.
F3. VOLUME buttons: to adjust the volume level.
F4. iPod 3.5 Input Connector: for the connection of an iPod or similar portable music device.
F5. iPod USB charging connector: for re-charging an iPod or similar portable music device.
The plastic
protective film
covering the
display may be
removed
