Package Contents
•
UltraATA 133 PCI adapter
•
Driver diskette
•
40-pin/80-wire Ultra ATA cable
•
This quick installation guide
Layout
IDE1 IDE2
Jumper On
(do not remove)
Pin1 Pin1
HDD
Activity
LED
Figure 1. UltraATA 133 PCI RAID layout
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer’s case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
