The TOOL BAR appears at the top and bottom of the Map Screen when
the vehicle is stationary.
The functions available in the Top Toolbar are to help you set your
preferred map viewing settings.
The name of the street you are currently on appears above the Bottom
Toolbar which has available your menu and navigation options.
Scale: Zoom In/Out
There are 11 map levels 15m, 30m,
60m, 120m, 600m, 1k, 2k, 8k, 30k,
100k, 400k.
Touch the scale icon
Touch to Zoom in.
Touch to Zoom out.
Touch to adjust the volume. Touch to the left or right of the
volume indicator to decrease or increase volume. Touch to
hear a sample voice at the current level.
Touch to mute the volume.
When MUTE is ON will show on the map screen.
Volume
Day/Night
Touch to switch the map
display colours from a day setting to
a night setting.
Day Mode
Night Mode
!
!
TOOLBAR
6
SET
UP
!
! The screen may be turned off of on by pressing
The screen dimmer can be turned on of off by
pressing and holding
POWER
POWER
