Page -2-
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN RESULT IN
DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN,
ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS MANUAL, LABELS, ETC. CONTACT
THE MANUFACTURER.
WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS
BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED
BY THE INSTRUCTIONS NEVER USE THE HEATER IN SPACES WHICH DO OR MAY CONTAIN VOLATILE OR AIRBORNE
COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT THINNER, DUST PARTICLES OR UNKNOWN
CHEMICALS.
HEATER SPECIFICATIONS
Type of Gas:
For use with Natural Gas Only
Gas Supply Pressure
to regulator
Maximum:
Minimum: 5" W.C. (1.25 kPa)
regulator out
4" W.C. (1.0 kPa)
Electrical Input:
115V, 60 Hz, 1Ø, 3a
Minimum Operating Voltage: 100V
Ignition:
Direct Spark, interrupted type
Primary Flame Control:
Solid State, 10-15 Second Timing
High Temperature Control:
240°F (116°C)
Minimum Ambient Temp. Rating
0°F (-17.8°C)
Model:
150-FASNG
Rating:
150,000 Btu/hr
(43.93 kW)
Fuel Consumption:
139 CuFt/HR
Fuel Orifice Port No.: 18
Fuel Orifice Port Size: 0.0595
Heated Air Output:
450 cfm
(12.74 cmm)
WARNING: NOT FOR HOME OR RECREATIONAL VEHICLE USE
WARNINGS
YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS, SO PLEASE
READ THESE INSTRUCTIONS BEFORE YOU OPERATE THIS HEATER.
Scheu Products Company, Incorporated
Mail: P.O. Box 250, Upland, CA 91785
Plant: 8855 Baker Ave., Rancho Cucamonga, CA 91730
Telephone: 800-325-7057
www.scheuco.com
8688
September 2002
1/2 psig (3.45 kPa)
Model
150-FASNG
ANSIZ83.7/CGA2.14-2000
