United States Stove Company 22AF - Manual (Page 22)

22 •DRAWINGS FOR ILLUSTRATION PURPOSES ONLY•
MODEL 22AF -
PARTS LIST
KEY PART NO. DESCRIPTION QTY.
1 69356 Firebox Weldment 1
2 88032 Flue Collar Gasket 1
3 40246 Flue Collar 1
4 25102R Cabinet Side 2
5 22682 Cabinet Back 1
6 25106R Cabinet Top 1
7 22761 Flue Collar Ring 1
8 22762 Forced Draft Ring 1
9 24959B Feed Door Hinge 1
10 25202B Ash Door Hinge 1
11 23800 Smoke Curtain 1
12 83445 1/4-20 x 1-1/4 Carriage Bolt 2
13 23787 Smoke Curtain Clip 2
14 83250 1/4-20 Kep Nut 2
15 23397 Baffle 1
16 40264 Front & Rear Liner 2
17 89066 Brick (4-1/2 x 9 x 1-1/4 THK.) 10
18 68238 Ash Pan Weldment 1
19 89319 Blower Gasket 1
20 22140 Junction Box Bracket 1
21 68234 Fan Limit Bracket Assembly 1
22 80145 Fan Limit Control 1
23 68231 Fan Limit Conduit Assembly 1
24 80131 4 x 4 Junction Box 1
N/S 80231 Junction Box Cover 1
25 68232 Blower Connection Conduit Assembly 1
26 80230 Blower Motor - 1/20 hp 1
27 40256 Grate Frame 1
28 40257 Shaker Grate 1
29 40260 Shaker Handle 1
* * 69355 Feed Door Assembly (Order ONLY if the entire Assembly is needed) 1
30 25105B Feed Door (Painted) 1
N/S 88066 5/8 Rope Gasket 4.58 ft
31 83872 Door Pin 2
32 89354 Feed Door Handle 1
33 83461 Handle Washer 1
34 24935 Ash Door Latch 1
35 83045A 3/8" SAE Flat Washer 1
36 83274 3/8-16 Lock Nut 1
37 23859B Spin Damper (Painted) 3
38 83345 3/8-16 x 1-3/4 Carriage Bolt 2
39 83178 3/8-16 Jam Nut 4
* 69388 Ash Door Assembly
(Order ONLY if the entire Assembly is needed)
1
40 25190B Ash Door 1
N/S 88033 3/8 Rope Gasket 2.42 ft
41 89354 Ash Door Handle 1
42 ------- Handle Bushings (Comes with Handle - 89354) 1
43 24935 Ash Door Latch 1
44 83045A 3/8" SAE Flat Washer 1
45 83274 3/8-16 Lock Nut 1
46 83503 3/8-16 x 2-1/2 Carriage Bolt 1
N/S = Not Shown
