Page 75
How Do I Use It?
Bicycle
Pedestrian
Status indicator strip
This is a complex indicator. In one strip it indicates the following status
information:
Icon Description
The sound output of TRAX350 is muted.
The sound output of TRAX350 is enabled.
TRAX350 records a Track log when GPS position is
available.
Track log recording is disabled.
Next two route events (Turn Preview fields)
There are two fields reserved on the Map screen to display the next two
manoeuvres (route events that are listed in the Itinerary). Both the type
of the event (turn, roundabout, exiting motorway, etc.) and distances are
displayed (the top manoeuvre shows the distance from the current GPS
position, and the lower manoeuvre shows the distance between the next
point and the final destination, or 3rd position).
Most of these icons are very intuitive and you also know them as road signs.
The following table lists some of the frequently shown route events. The
same symbols are used in both fields:
