2
Front Panel
1. CHANNEL - This control is used to manually select the desired
Communication Channel (01 - 28 and 60 - 88), or Weather
Channel (0 - 9).
2. LCD Panel - Indicators for TX, SCAN, TRI, U, I, C, HI, LO, MEM,
WX, WX ALERT, and Channel Number.
3. POWER/VOLUME (On/Off/Volume) - Turns the OCEANUS On or
Off and varies the audio output.
4. WX (Weather mode On/Off)
5. 16/9 (Channel 16/Channel 9; also located on microphone)
6. MEM (Memory)
7. H/L (Output Power Hi/Low)
8. STEP (also located on microphone)
9. SQUELCH - Eliminates background noise when no signal is being
received.
10. Press - to - talk (PTT) Switch - Press to transmit and release to
receive.
Note: Items 4 through 8 are Multi-Function keys. Refer to the
“Multi-Function Keys” section for detailed descriptions.
Controls and Indicators
1
8
2 3
4 5 6
5
10
7 8 9
