all Mounting the Base
(To AC outlet)
Wall plate
Removing the wall-mount bracket
At the bottom of the base,
pinch the two "nose" of
the wall-mount bracket
as shown, and then
slide the bracket away
from the base.
Place the mounting slots over
the pins on the wall plate.
Slide the base
down to lock it
into place.
Note:. Mounting.the.phone.directly.on.the.wall
Be.sure.the.wall.is.capable.of.supporting.the.
weight.of.the.phone,.and.use.the.proper.type.of.
anchoring.device.for.the.wall.material.
Insert.two.#10.screws.(minimum.length.of.1. 3 /
8
.
inches,.not.supplied).into.the.wall,.3. 15 /
16
.inches.
apart...
Leave.the.screw.heads. 1 /
8
.inch.away.from.the.
wall.to.allow.room.for.mounting.the.phone..
Align.the.mounting.slots.over.the.screws.and.
slide.the.base.down.into.place.as.shown.above.
•
•
•
•
