EXTERNAL
EQ
UIPMENT
SETUP
16
DVD SETUP
EXTERNAL EQUIPMENT SETUP
When connecting Component cable
Y
L
R
P
B
P
R
VIDEO
AUDIO
VID
COMPONENT IN
(480i/480p/720p)
RGB (PC
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the TV
Y
P
B
P
R
Video output ports
on DVD player
Y
Y
Y
Y
P
B
B-Y
Cb
Pb
P
R
R-Y
Cr
Pr
Connect the video outputs (Y, P
B
, P
R
) of the DVD to
the C
CO
OM
MP
PO
ON
NE
EN
NT
T IIN
N V
VIID
DE
EO
O jacks on the set.
Match the jack colors
(Y = green, P
B
= blue, and P
R
= red).
Connect the audio outputs of the DVD to the
C
CO
OM
MP
PO
ON
NE
EN
NT
T IIN
N A
AU
UD
DIIO
O jacks on the set.
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select C
Co
om
mp
po
on
neen
ntt input source by using the IIN
N P
P U
U T
T
button on the remote control.
■
Refer to the DVD player's manual for operating instructions.
