PARTS INFORMATION
[email protected] Page 6
TC- 4700
MUFFLER & CLUTCH • FIGURE 4
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
4-1 7380422020 PROTECTOR,MUFFLER 1
4-2 99461050124 BOLT,HEX,5X12S 1
4-3 99461050124 BOLT,HEX,5X12S 1
4-4 99201050061 WASHER,5 1
4-5 99053060653 SCREW,HEX,6X65 2
4-6 99201060011 WASHER,6 2
4-7 7040422S90 MUFFLER 1
4-9 75104200201 GASKET,MUFFLER 1
4-10 7210430090 TAIL PIPE SET 1
4-11 99414040081 SCREW,4X8 2
4-14 73704230200 GASKET,MUFFLER 1
4-16 1330423020 SHIELD,HEAT 1
4-23 99461050184 BOLT,HEX,5X18,S 2
4-24 99461050254 BOLT,HEX HOLE,5X25S 2
4-25 65304200200 BRACKET,TANK 1
4-26 65506100200 CUSHION,TANK 2
4-81 35910112203 WASHER,CLUTCH B 2
4-82 2900427080 SHOE,CLUTCH 2
4-83 3420427020 SPRING,CLUTCH 1
4-84 99204100030 WASHER,WAVE,10 2
4-85 3570136U200 BOLT,STEP,CLUTCH 2
