Page 4
4
48/42U
J
J
J
M
M
48/42U
25U
I
I
I
K
42U
48U
1-6
1-7
1 – Frame Assembly
(continued)
(For 25U enclosures, skip this step.) Attach the cable manager
brackets
J
to the vertical sections with four M5 x 10 mm screws
and washers
M
as shown. (For 48U enclosures, use the upper
set of holes. For 42U enclosures, use the lower set of holes. The
brackets will face downward.)
Use two M6 x 12 mm flat-head screws
K
to attach each hinge
I
as shown. Orient each hinge so that the pin is closer to the
outside of the frame than the inside.
1-6
1-7
