64
C40
1 103 7064 Base frame 1
2 103 7065 Front foot 1
3 103 7066 Rear foot 1
4 533 7080 Foot cover 4
*5 M10x25 DIN 912 Screw 4
*6 M10 DIN 127 Spring washer 4
*7 M10 DIN 125 Washer 4
8 173 7029 Chain cover, R & L 1
9 533 7041 Turning plate cover 2
10 203 7057 Upright tube, (incl. 62) 1
11 403 7035 Cable 1
12 403 7034 Servo motor 1
*13 M8x15 ISO 7380 Allen head bolt 6
*14 M8 DIN 127 Spring washer 14
*15 M8 DIN 125 Washer 8
16 343 7019 Axle support 1
17 203 7045 Handle bar, RH (incl. 62,63,64) 1
18 203 7046 Handle bar, LH (incl. 62,63,64) 1
*19 M8 DIN 440 Washer M8 OD 28mm 2
20 203 7024 Swivl tube EUR (incl 47) 2
- 203 7038 Swivl tube, USA (incl 47) 2
*21 653 7036 Spring knob, EUR 2
* - 653 7032 Screw, USA 2
22 103 7068 Pedal tube, left 1
23 363 7005 Pedal, pair (incl 29) 1
*24 M6x60 DIN 603 Screw 4
*25 653 7022 Knob dawl 4
*26 M6 DIN 127 Spring washer 4
*27 M6 DIN 125 Washer 4
28 103 7067 Pedal tube, right 1
30 M5x10 DIN 7985 Screw 2
31 233 7015 Computer 1
32 203 7052 Handlebar (incl.36,37,42,43) 1
*33 M8x45 ISO 7380 Screw 2
*34 533 7048 End cap 1
*35 503 7025 Fix handlebar bracket 1
37 403 7061 Pulse grip unit (incl. 36) 2
38 403 7020 EU Transformer, EUR 1
38 403 7020 AUS Transformer, AUS 1
38 403 7020 GB Transformer, GB 1
38 403 7020 JPN Transformer, JPN 1
38 403 7020 USA Transformer, USA 1
39 3,9x25 DIN 7981 Screw 7
40 3,9x32 DIN 7981 Screw 1
41 653 7041 Screw 10-24 UNCx19 4
42 213 7014 Fix handlebar grip 2
43 533 7039 Fix handlebar end cap 2
44 72 0813 100 1 Sleeve 2
45 533 1048 Wheel 2
46 673 500 88 Caps 2
47 523 9006 Bearing 8
48 503 7027 Pedal fix bracket 2
49 8x14x03 DIN 988 Washer 2
50 M8 DIN 9021 Washer 2
51 M8x20 ISO 7380 Screw 2
52 533 7079 Bushing 4
53 M10 DIN 125 Washer 4
54 M10x68 ISO 7380 Allen head bolt 2
55 M10 DIN 985 Nylock nut 2
56 533 7075 Pedal rear cover 2
57 M8x25 ISO 7380 Allen head bolt 2
58 343 7018 Pedal tube shaft 2
59 533 7043 End cap 2
60 653 7025 Washer 2
61 533 7045 Plastic insert 2
62 533 7044 Plug axle support 6
63 213 7015 Handle grip, pair 2
64 533 7076 Handlebar end cap 2
65 M5x10 DIN 7985 Screw 2
66 523 409 85 Bearing 4
68 M6x10 DIN 7985 Screw 1
69 503 7017 Sensor bracket 1
70 403 7033 Sensor wire 1
71 3,5x13 DIN 7504-M Screw 2
72 403 7036 DC-cable 1
73 M8x16 DIN 7985 Screw 4
74 513 7016 Magnetic holder bracket 1
75 523 7014 Spacer sleeve 3
76 M6x14 DIN 933 Screw 3
77 M6 DIN 9021 Washer 3
78 513 7001 Bracket (incl. 66, 79) 1
79 17 DIN 417 Clip C17 3
80 643 7001 Carge spring 1
81 503 7018 Keep back bracket 1
82 503 7019 Spring bracket 1
83 M6x15 DIN 7985 Screw 1
84 303 7002 Flywheel (incl. 85 - 90) 1
85 523 504 84 Bearing 2
86 343 7021 Flywheel axle 1
87 12 DIN 471 Clip C12 2
88 653 7038 Washer 1mm 1
89 M10 DIN 125 Washer 2
90 653 7026 3/8” Wh nut 2
91 373 7006 Magnetic bow 1
92 M8x52 DIN 931 Screw 1
93 M8 DIN 985 Nylock nut 1
94 223 7005 Metal wire 1
95 643 7002 Spring 1
96 263 7007 Pulley 1
97 343 7020 Axle for pulley 1
98 503 7011 Safe bracket 1
99 M6 DIN 985 Nylock nut 4
100 M6x18 DIN 933 Screw 4
101 443 7003 Belt 1
102 403 7017 Magnet 1
103 433 7017 Turning pedal (incl. 104) 2
105 M8x25 DIN 933 Screw 2
106 653 7037 Screw 10-24 UNCx19 2
108 503 7022 DC-wire brcacket 1
109 503 7024 Bracket 1
110 653 7042 Screw 10-24 UNCx16 2
111 M8 DIN 125 Washer 2
- 423 0074 Lable set 1
- 553 7010 Assembly kit (incl. *) 1
- 583 7016 Owner’s manual 1
