OMEGA Antenna Installation Manual 3
Chapter 1
Elevated-Feed Antenna
The OMEGA elevated-feed antenna is a very compact yet high-performance omni-directional
antenna. It is ideally suited for applications where high gain and wide coverage is desired.
Parts List
As you unpack your antenna you should find the following items:
! One elevated feed antenna
! One bag containing the following mounting hardware
−
A cable with a round, gold antenna mount at one end
−
Two “L” brackets and six screws for wall-mounting
the antenna
−
Two fasteners for pole-mounting the antenna
! This manual
If any of these items are missing or damaged, please contact Telenetics immediately.
