SERVICE PARTS LIST
19 Ultra-Aire 135H Installer’s & Owner’s Manual
Item Part No. Description
1 4021589 Capillary Tube, .059" X .124" X 28.00" (not shown)
2 4026827 Compressor, Carlyle (EBA105111A)
3 4026828 Compressor Overload (EBA105111A) (not shown)
4 4022484 Compressor Relay, SPST, 24 Vac, 30A
5 4027108 Compressor Run Capacitor, 30 MFD
6 4021396 Condenser Coil
7 4021470 Defrost Thermostat
8 4021648 Defrost Thermostat Mounting Clip (not shown)
9 4021395 Evaporator Coil
10 4025076 Impeller Fan
11 4020924 Impeller Fan Relay, SPDT, 24 Vac, 15A
12 4025224 Impeller Fan Run Capacitor, 15 MFD
13 4025087 Filter/Drier
14 4022219 Low Pressure Control (not shown)
15 4022487 Transformer, 120/24 Vac, 40 VA
not shown
4017414 Accumulator
not shown
4025249 Collar 10"
not shown
4024368 Collar 10" no crimp
not shown
4025082 Cord
not shown
4025084 Wire Harness
not shown
4025086 Wire Harness, low voltage
not shown
4025242 Wiring Diagram
