5. ELECTRONIC CONTROL INSTRUCTIONS
17
5-1. FREEZER CONTROL
5-1-1. How to use the display PCB panel
5-1-2. Manual Defrost Function
- 88 LED
- It indicates setting temperature,
except defrost function -Door Open LED
-Temperature can be controlled by the user.
-Factory setting is at level "2
". Setting can
be changed by pressing up/down button.
Press temperature setting UP/DOWN key for 2 econds at
the same time, manual defrost mode will start.
If you press UP/DOWN key for 2 seconds again on defrosting
manual defrost will be cancelled and it will revert to nomal
mode after 10 minutes of pause(Display panel indicates “DF”
for pause period)
25 W
R7494-010
16
MAIN COMPONENTS
4-6. CONDENSER FAN MOTOR
MODEL
Voltage
Motor Model
Part code
115 V / 60 Hz
SR-043
R7423-020
4-8. LAMP
MODEL
Voltage
Spec
Part code
115 V / 60 Hz
4-9. MAIN PCB
MODEL
Voltage
Part code
115 V / 60 Hz
R7103-260 R7103-250 R7103-260
4-10. DISPLAY PCB
MODEL
Voltage
Part code
115 V / 60 Hz
R7113-190
4-7. DEFROST HEATER
MODEL
Voltage
Spec
Part code
115 V / 60 Hz
445 W
R7303-400
600 W
R7303-410
MSR-23NM MSR-49NM MSF-23NM MSF-49NM MSR-23G-1 MSR-49G-2
MSR-23NM MSR-49NM MSF-23NM MSF-49NM MSR-23G-1 MSR-49G-2
MSR-23NM MSR-49NM MSF-23NM MSF-49NM MSR-23G-1 MSR-49G-2
MSR-23NM MSR-49NM MSF-23NM MSF-49NM MSR-23G-1 MSR-49G-2
FLUORESCENT 32W/865RS
R7494-150
MSR-23NM MSR-49NM MSF-23NM MSF-49NM MSR-23G-1 MSR-49G-2
4-11. BALLAST
MODEL
Voltage
Spce
Part code
120V / 60Hz
32W
R7553-011
MSR-23G-1 MSR-49G-2
