Tanaka THT-2530/2540 - Manual (Page 14)

www.tanaka-usa.com
PARTS INFORMATION
[email protected] Page 12
THT2530/40
HANDLE, THROTTLE COMPONENTS • FIGURE 8
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
01 053-33231-22 GRIP,HANDLE"A" 1
02 054-33231-23 GRIP,HANDLE"B" 1
03 230-33210-201 LEVER,THROTTLE 1
04 231-33210-200 LEVER,SAFETY 1
05 061-32600-201 SPRING,THROTTLE LEVER 1
06 170-32465-80 BUTTON, STOP SWITCH 1
07 925-32530-20 DECAL,STOP BUTTON 1
10 765-32120-20 CAP 1
13 994-16040-301 SCREW 4 X 30 / WS 2
14 994-16040-251 SCREW,4X25/WS 1
15 055-33185-90 ASSY,HANDLE GRIP 1
16 050-33185-80 HANDLE A 1
17 885-0650J-80 WIRE,THROTTLE 1
18 164-10015-00 TUBE,PROTECTION 1
19 994-16040-161 SCREW 4 X 16 /WS 3
22 991-78040-010 NUT,LOCK 4 6
23 990-11030-101 SCREW,3X10 1
24 258-11650-20 BUTTON,STOP 1
25 198-33130-200 CLAMP,CORD 1
33 994-61050-124 BOLT,HEX,5X12S 4
35 058-33185-20 BRACKET,HANDLE 1
36 060-33185-20 RUBBER,HANDLE DAMPER 2
75 813-20000-200 WRENCH,HEX,4 1
76 036-29331-501 SPANNER,COMBI 1
