Troy-Bilt 7524 User Manual
Page 23
23
Models 7524 / 8526
Ref.
No.
Part No.
Part Description
1.
731-04067
Handle Panel (8526)
2.
731-04059
Handle Panel (7524)
3.
710-1003
Special B Screw*
4.
725-1672
Lens Assembly*
5.
747-1136
Lamp Retainer*
6.
725-1658
Halogen Lamp*
7.
629-0059
Lamp Wire Harness*
8.
726-0100
Push Cap
9.
720-0201A
Chute Crank Knob
10.
747-0737
Upper Chute Crank
11.
684-0053B
Chute Crank Assembly, Lower
12.
736-0185
Fl-Wash. .375 I.D. x .738 O.D.
13.
714-0104
Hairpin Clip
14.
741-0475
Plastic Bushing
15.
705-5266
2 pc. Chute Crank Brkt.
16.
736-0270
Bell Washer
17.
712-0287
Hex Nut 1/4-20 Thd.
18.
736-0275
Fl-Wash. .344 I.D. x .688 O.D.
19.
736-0119
L-Wash. 5/16
20.
710-0643
Hex Hd. Cap Scr. 5/16-18 Thd.
21.
710-0788
TT-Tap Screw 1/4-20 Thd.
22.
684-0008A
Shift Arm Assembly
23.
747-0621
Lower Shift Rod
24.
736-0451
Saddle Washer .320 I.D. x .93 O.D.
25.
720-0284
Knob
26.
710-0449
Carriage Screw 5/16-18, Gr. 5
27.
750-0963
Clutch Rod Connector
28.
711-0677
Ferrule
29.
710-0458
Carriage Bolt
30.
736-0242
Bell Washer
31.
712-3068
Hex L-Nut 5/16-18 Thd.
32.
720-0232
Shift Knob
33.
710-3015
Hex Hd. Cap Screw 1/4-20
34.
714-0145
Click Pin
35.
712-0116
Jam L-Nut 3/8-24 Thd.
36.
732-0193
Compression Spring
37.
736-0105
Spring Wash. .401 I.D. x .870 O.D.
38.
710-0459A
Hex Hed. Cap Screw 3/8-24 Thd.
39.
749-0951
Lower Handle
40.
749-0953A
Upper Handle, LH
41.
749-0952A
Upper Handle, RH
42.
712-0271
Hex Sems Nut
43.
710-1880
Hex Patch Screw 5/16-18 Thd.
44.
747-0620A
Upper Shift Rod
45.
720-0274
Foam Grip
* Model 8526 only
